Control and Update Infographic with Sliders in After Effects

Learn how to create an adjustable pie chart infographic, where you can control and update all the information using sliders.

Part 1

In Part I, we will be building the infographic itself.

Part 2

In Part I, we will be building the infographic itself.

The Expressions Used in Part 1

The below expression is used on the Transition Completion on the Radial Wipe effect, on the first circle “1”

slider = thisComp.layer("CONTROLS").effect(name)("Slider");
100 - slider;

The below expression is used on the Start Angle on the Radial Wipe effect, on the second circle “2”

TC = thisComp.layer(index+1).effect("Radial Wipe")("Transition Completion");
A = thisComp.layer(index+1).effect("Radial Wipe")("Start Angle");
(100-TC) * 3.6 + A;

The Expressions Used in Part 2

The below expression is used on the Rotation of “Null 01”

T = thisComp.layer("1").effect("Radial Wipe")("Transition Completion")
A = thisComp.layer("1").effect("Radial Wipe")("Start Angle");
R1 = A * -3.6;
R2 = (R1+360) / 2 + A;

The below expression is used on the Rotation of your number to counter the rotation of the chart and keep it upright at all times

r = thisComp.layer("null 01").transform.rotation;
-r

The below expression is added to ‘Source Text’ of each number used

n = thisComp.layer("PIE CONTROLS").effect(name)("Slider");
Math.round(n)
